Ultra-High Molecular Nyhav Polyethylene (UHMWPE) hlua
Ultra-High Molecular Nyhav Polyethylene (UHMWPE) Rope Introduction To Products Product Introduction: Cov khoom no yog high-kev ua haujlwm hluavtaws fiber ntau woven los ntawm ultra-siab molecular hnyav polyethylene (UHMWPE) fibers. Nrog qhov hnyav molecular siab heev, UHMWPE fibers muaj zoo heev ...
Hauj lwm lawm
Yog hais tias lub ultra- siab molecular hnyav polyethylene (uhmwpe) hlua caters rau koj yuav tsum tau, txais tos mus yuav los yog lag luam wholesale nrog peb lub Hoobkas. Raws li ib qho ntawm cov ua lag luam thiab cov muag khoom nyob rau hauv Suav teb, peb yuav muab koj cov nqi sib tw tshaj plaws thiab cov kev pabcuam zoo tshaj plaws.
Ultra-High Molecular Nyhav Polyethylene (UHMWPE) hlua
Taw Qhia Rau Cov Khoom
Cov Khoom Taw Qhia: Cov khoom no yog siab -kev ua tau zoo hluavtaws fiber ntau woven los ntawm ultra-siab molecular hnyav polyethylene (UHMWPE) fibers. Nrog rau qhov hnyav molecular siab heev, UHMWPE fibers muaj cov khoom zoo heev, uas ua rau txoj hlua khi nrog qhov zoo ntawm ntau yam. Kev sib xyaw ua ke zoo tshaj plaws ntawm "ultra- siab zog" thiab "lub teeb yuag" yog ib qho ntawm nws cov kev sib tw tseem ceeb piv nrog ntau cov hlua khi.
Daim ntawv thov teb
Performance Feature
Qauv: 8-strand, 12-strand
Qhov ceev: 0.97g / cm (Floats ntawm dej)
Melting Point: 145 ° C
Elongation ntawm Break: 3.5%
Abrasion Resistance: Zoo heev:
UV Resistance: Zoo heev
Corrosion Resistance: Zoo heev
Ultra-High Strength: Tib lub zog zoo li steel cables nrog tib txoj kab uas hla
Lub teeb: Tsuas yog 12% ntawm qhov hnyav ntawm cov hlau thiab 15% -25% ntawm lwm cov hlua fiber ntau nrog tib lub zog tawg
Tsawg Elongation: Elongation thaum so yog ze rau ntawm cov hlau
Qhov Loj: 40% -60% ntawm txoj kab uas hla ntawm lwm cov hlua fiber ntau nrog tib lub zog tawg
8-strand & 12-strand Parameter Table
|
Loj |
Qhov hnyav |
Txoj Kev Ua Zog |
|||
|
Txoj kab uas hla (mm) |
Lub voj voog (inch) |
Qhov hnyav ib Meter (g / m) |
Qhov hnyav (kg / 220m) |
Lub zog tawg (KN) - Unknoted |
Rhuav Lub Zog (KN) - Nrog Qhov Muag Splice |
|
6 |
3/4 |
23 |
5.1 |
39 |
35 |
|
8 |
1 |
40 |
8.8 |
71 |
64 |
|
10 |
1-1/4 |
61 |
13.4 |
106 |
95 |
|
12 |
1-1/2 |
83 |
18.3 |
150 |
135 |
|
14 |
1-3/4 |
117 |
25.7 |
211 |
190 |
|
16 |
2 |
151 |
33.2 |
267 |
240 |
|
18 |
2-1/4 |
184 |
40.5 |
322 |
290 |
|
20 |
2-1/2 |
227 |
49.9 |
384 |
346 |
|
24 |
3 |
324 |
71.3 |
533 |
480 |
|
28 |
3-1/2 |
444 |
97.7 |
704 |
634 |
|
32 |
4 |
589 |
129.6 |
918 |
826 |
|
36 |
4-1/2 |
720 |
158.4 |
1104 |
994 |
|
40 |
5 |
880 |
193.6 |
1329 |
1196 |
|
42 |
5-1/4 |
979 |
215.4 |
1459 |
1313 |
|
44 |
5-1/2 |
1078 |
237.2 |
1589 |
1430 |
|
46 |
5-3/4 |
1171 |
258.6 |
1698 |
1526 |
|
48 |
6 |
1264 |
278.1 |
1807 |
1628 |
|
50 |
6-1/4 |
1358 |
305.4 |
1971 |
1774 |
|
52 |
6-1/2 |
1512 |
332.6 |
2136 |
1922 |
|
54 |
6-3/4 |
1636 |
359.9 |
2300 |
2070 |
|
56 |
7 |
1760 |
387.2 |
2464 |
2218 |
|
58 |
7-1/4 |
1885 |
414.7 |
2622 |
2360 |
|
60 |
7-1/2 |
2010 |
442.2 |
2778 |
2500 |
|
62 |
7-3/4 |
2135 |
469.7 |
2936 |
2642 |
|
64 |
8 |
2260 |
497.2 |
3092 |
2783 |
|
66 |
8-1/4 |
2423 |
533.1 |
3293 |
2964 |
|
68 |
8-1/2 |
2585 |
568.7 |
3496 |
3146 |
|
70 |
8-3/4 |
2748 |
604.6 |
3697 |
3327 |
|
72 |
9 |
2910 |
640.2 |
3898 |
3508 |
|
74 |
9-1/4 |
3065 |
674.3 |
4080 |
3672 |
|
76 |
9-1/2 |
3220 |
708.4 |
4263 |
3837 |
|
78 |
9-3/4 |
3375 |
742.5 |
4444 |
4000 |
|
80 |
10 |
3530 |
776.6 |
4628 |
4165 |
|
82 |
10-1/4 |
3708 |
815.8 |
4837 |
4353 |
|
84 |
10-1/2 |
3885 |
854.7 |
5047 |
4542 |
|
86 |
10-3/4 |
4063 |
893.9 |
5256 |
4730 |
|
88 |
11 |
4240 |
932.8 |
5464 |
4918 |
|
90 |
11-1/4 |
4430 |
974.6 |
5678 |
5104 |
|
92 |
11-1/2 |
4615 |
1015.3 |
5893 |
5310 |
|
94 |
11-3/4 |
4803 |
1056.7 |
6108 |
5497 |
|
96 |
12 |
4990 |
1097.8 |
6322 |
5690 |
|
100 |
12-1/2 |
5515 |
1213.3 |
6930 |
6230 |
|
120 |
15 |
6040 |
1328.8 |
7522 |
6770 |
|
140 |
17 |
7980 |
1755.6 |
9856 |
8870 |
