Lub Hniav Roj Hmab Fender

Lub khob hliav tshuaj-hom khoom siv roj hmab yog lub tswv yim ntawm cov roj hmab ruaj khov yog qhov ua conical zoo heev uas tuaj yeem siv ntau yam ntawm...

Xa kev nug

Hauj lwm lawm

Lub khob hliav tshuaj-hom khoom siv roj hmab yog tus tswv cuab thib peb ua tau zoo heev txawm tias muaj cov ncej loj heev.

Roj Hmab Roj Hmab yog ib qho kev siv roj av thiab cov duab sib xyaw ua ke ua rau ntau tus cwj pwm ua kom zoo nkauj.

Lub khob hliav qab cov fenders ntau hauv qhov siab los ntawm 300 txog 2. Lub khob cooj siab heev ua rau lub khob cooj siab heev ua rau cov khoom sib xyaw loj heev

Txuag geometry, ruaj khov shear tsis kam .

Loj deflection, kev ua haujlwm siab .

Kev xaiv ntau ntawm cov roj hmab cov pa roj hmab tuaj yeem txhawb nqa loj panels .

Zoo kawg angular compression nrog tsis muaj kev ua haujlwm poob ntawm kev tiv tauj cov ces kaum txog 10℃.

Ntau yam ntawm qhov ntau thiab tsawg kom tau raws li ntau yam tsim .

kev qhia tshwj xeeb	H	Φ1	Φ2	Φ3	Φ4	n	m	M	Qhov hnyav hnyav (kg)
500H	500	425	325	675	750	4	M24	30	140
600H	600	510	390	810	900	6	M24	30	232
700H	700	595	455	945	1050	6	M30	38	395
800H	800	680	520	1080	1200	6	M36	44	540
900H	900	765	585	1215	1350	6	M36	44	760
1000H	1000	850	650	1350	1500	6	M42	50	1015
1100H	1100	935	715	1485	1650	6	M42	50	1505
1150H	1150	998	750	1550	1725	6	M42	50	1600
1200H	1200	1020	780	1620	1800	8	M42	50	1960
1300H	1300	1105	845	1755	1950	8	M48	60	2400
1400H	1400	1190	930	1890	2100	8	M48	60	3060
1600H	1600	1360	1060	2160	2400	8	M48	60	4600
1800H	1800	1530	1190	2430	2700	10	M56	70	6600

Qhov loj me tuaj yeem yog customized thaum thov . (unit: mm)

Lub Npe		Ua ntaub ntawv	Ntaub ntawv
Lub plhaub tsheb		Nqus nkoj nkoj berthing, tiv thaiv dock thiab nkoj .	Yas
Tus ncej pem hauv ntej		Txo cov npoo av siab, tiv thaiv kev tiv thaiv quab yuam los ntawm tus fender, thiab nce thaj tsam tiv tauj .	Q235 xim pleev xim,
Tus ncej pem hauv ntej			Q235 kub dip galvanizing
Ncej pem hauv ntej		Txo cov coefficient ntawm kev txhuam kom tiv thaiv lub hull .	Ultra siab molecular hnyav polyethylene
Ua ntej tsim teeb tsa	Prelounto Bolts thiab Ceev	Ruaj khov rau fender mus rau hauv paus .	Stainless hlau (lossis Q235)
	Pretet u-ntiv nplhaib	Txuas cov saw .	Q235 xim pleev xim,
	Pretet u-ntiv nplhaib	Txuas cov saw .	Q235 kub dip galvanizing
Txuas Txuas Rod Bolts, Neeg Ntseej		Txuas cov khoom siv xws li Fenders thiab Panels .	Stainless hlau lossis kub-dip galvanizing
Txoj hlau	Counterweight saw	Txhawb nqa vaj huam sib luag pem hauv ntej kom tsis txhob sagging .	Q235 kub dip galvanizing lossis ci xim
	Cov saw nro	Txwv tsis pub fender deflection thaum ntxhov siab qhov qis dua .	Q235 kub dip galvanizing lossis ci xim
	Shear saw	Tiv thaiv kev ua haujlwm fender shear deflection .	Q235 kub dip galvanizing lossis ci xim

Cov txiaj ntsig zoo thiab areformance ntawm lub khob-hom khoom noj haus luam yeeb

Kev qhia tshwj xeeb	Tsim Kev Ua Haujlwm Txheej Txheem Txheej Txheem 70%								Qhov siab tshaj plaws compressive deformation yog 72.5%
	Rs		P		Tus ro		Rl		Rs		P		Tus ro		Rl
	R	E	R	E	R	E	R	E	R	E	R	E	R	E	R	E
500H	335	79	268	63	200	47	165	47	380	90	311	70	232	50	193	41
600H	480	157	382	127	283	94	225	94	542	161	429	129	319	104	258	85
700H	652	235	522	181	384	150	308	150	691	243	568	192	426	154	341	124
800H	862	368	706	294	502	224	402	224	930	380	833	316	576	252	428	208
900H	1078	494	862	399	635	306	508	306	1189	517	957	431	703	334	558	270
1000H	1339	669	1078	541	784	437	628	437	1507	735	1213	588	882	478	698	380
1100H	1430	830	1146	650	927	495	800	495	1570	865	1259	681	1019	527	833	432
1150H	1764	1029	1392	882	1038	666	830	666	1985	1103	1593	938	1152	717	919	588
1200H	1846	1093	1496	952	1106	705	890	705	2045	1149	1665	998	1227	739	985	587
1300H	2125	1585	1705	1310	1320	1043	1125	1043	2312	1640	1900	1360	1537	1077	1200	800
1400H	2255	1686	1804	1349	1443	1079	1150	1079	2506	1756	2005	1405	1604	1124	1278	896
1600H	3024	2419	2268	1935	1814	1548	1418	1548	3150	2520	2520	2016	2016	1613	1575	1285
1800H	3750	3538	3000	2830	2401	2264	1912	2264	4166	3686	3333	2948	2667	2359	2125	1880
